Description
The E-5005 Transparent Braided Hose is designed for high-performance fluid transfer in industrial and general applications. Manufactured using premium plasticized PVC, this hose features a transparent construction that allows easy monitoring of fluid flow. Reinforced with a single braid of high-strength synthetic fiber, it offers excellent pressure resistance and durability. Suitable for factory water supply, drainage systems, and air piping in industrial equipment, this hose ensures reliable and efficient operation. It is also available in regular and heavy-duty variants to meet diverse application requirements.
Construction
-
Tube & Cover : Plasticized PVC, Transparent
-
Reinforcement : Single braid of Synthetic Fiber
Application
-
Factory water supply and drainage systems
-
Air piping for industrial equipment
-
Suitable for rock drill hose applications
-
Available in regular and heavy-duty types
Technical Details
| Inch | ID (mm) | OD (mm) | WP (Bar) | WP (PSI) | BP (Bar) | BP (PSI) | BR (mm) | Weight (g/m) |
|---|---|---|---|---|---|---|---|---|
| 1/2 | 12.7 | 17.0 | 25 | 360 | 75 | 1090 | 75 | 230 |
| 5/8 | 16.0 | 22.0 | 22 | 320 | 72 | 1090 | 75 | 320 |
| 3/4 | 19.0 | 26.7 | 20 | 290 | 72 | 1090 | 75 | 380 |
| 1 | 25.4 | 33.0 | 15 | 220 | 50 | 725 | 50 | 490 |
