LA1010 USB Logic Analyzer, Full 16 Channels (2 PWM Channels) 100MHz Sampling Rate PC Software Logic Analyzer for PC Analysis on Win XP/7/8/10 Mac OS Linux Vista

Unlock powerful digital signal analysis with the LA1010 USB Logic Analyzer. Perfect for engineers, hobbyists, and developers working on embedded systems, the LA1010 Logic Analyzer delivers accurate waveform observation and protocol decoding for a wide range of applications.Supported OS:Windows XP, Vista, Windows 7/8/10 (32bit/64bit), Mac OS, LinuxSupported Standard Protocols:UART/RS-232/485, I2C, SPI, CAN, DMX512, HDMI CEC, 12S/PCM, JTAG, LIN, Manchester, Modbus, 1-Wire, UNI/0, SDIO, SMBus, USB1.1, PS/2, NEC InfraRed, Parallel, to be updated from time to timeSPECIFICATIONModel: LA1010Channels: 16 input channels (Channel-0 to Channel-15) (2 PWM channels included)Sampling Rate: 100M@3CH, 50M@6CH, 32M@9CH, 25M@12CH, 16M@16CHMax. Sampling Depth: 10G, USB2.0 Interface (actual depth may be limited by the PC’s memory capacity)Adjustable Threshold: -4V to +4V, step: 0.01VWithstand Voltage: -50V to +50VFastest Digital Signal: 20MHzMin Pulse Width: 20nsPWM Frequency Range: 0.1MHz to 10MHz, step: 10nsPWM Output Voltage: +3.3VPWM Output Impedance: 50ΩStandby Current: 100mAMax. Operating Current: 150mADimensions: 3.74*2.17*0.71in / 95*55*18mmPACKAGE1 x LA1010 Logic Analyzer3 x 9P Test Set2 x 2P Test Set20 x Test Hook Clip1 x USB-C Cable with USB-A Adapter1 x Storage Case1 x Manual

• USB Logic Analyzer can simultaneously sample up to 16 digital signals (2 dedicated PWM channels included), and supports Windows XP/Vista/7/8/10 (32/64bit), Mac OS, and Linux, ideal for complex multi-signal projects MCU, ARM, FPGA, etc
• Logic Analyzer captures detailed data with a max. sampling rate of 100MHz (variable by channel count); NOTE: For best results, set the sampling rate to at least 5-10 times the highest frequency of the signal you’re testing
• USB Logic Analyzer easily visualizes and decodes waveforms via advanced PC software, linked positioning allowing you to correlate waveform windows and analysis results for fast, convenient signal exploration
• Logic Analyzer supports protocols, such as UART, RS-232/485, I2C, SPI, CAN, DMX512, HDMI CEC, 12S/PCM, JTAG, LIN, Manchester, Modbus, 1-Wire, UNI/0, SDIO, SMBus, USB1.1, PS/2, NEC InfraRed, Parallel, to be updates from time to time
• Logic Analyzer features a compact, sturdy plastic shell for portability and reliability on the workbench or in the field, suitable for debugging and analysis of microcontrollers, ARM processors, and FPGA hardware, developing and troubleshooting communication protocols, and monitoring, recording, and analyzing digital signals long-term
